| Type (Kind) | Power Transmission 4-Leg Lattice Tower |
|---|---|
| Height | 10m – 80m (Customizable) |
| Surface Treatment | Hot-dip Galvanization (ASTM A123) |
| Hoisting Method | Segmented Hoisting / Internal Gin Pole |
| Material | High-Strength Steel Q235B / Q355B / Q420 |
Product Introduction
Engineering intelligence builds better towers. CLEVERTOWER® delivers safe, reliable, and cost-efficient tower solutions through proven engineering experience and rational structural design.
CT-P-50-L-11F01
Professional High Voltage Hot-Dipped Galvanized Lattice Steel Transmission Structure Electric Power Tower for Global Grid
Product Details
High-Strength Lattice Engineering
Constructed with premium Q355B/Q420 structural steel, this 4-leg lattice tower provides exceptional rigidity and load-bearing capacity for high-voltage transmission lines, ensuring long-term grid stability and safety.
Extreme Weather Resistance
Features comprehensive hot-dip galvanization (minimum coating 86μm) that meets ASTM A123 standards, providing 50+ years of maintenance-free corrosion protection even in humid or coastal environments.
Modular Assembly Design
The precision-engineered bolted connection system allows for compact shipping and simplified on-site assembly, significantly reducing logistics costs and installation time in challenging or remote terrains.
Advanced Wind & Seismic Stability
Designed with a wide-base 4-leg geometry, the tower is optimized for high wind load scenarios (up to 50m/s) and seismic activity, maintaining structural integrity under extreme mechanical stress.
Versatile Transmission Capability
Engineered to support multiple circuit configurations and heavy insulator strings, making it the ideal professional solution for 110kV, 220kV, and 500kV power transmission and distribution infrastructure.
| Tower Type | 4-Leg Angular Steel Lattice Structure |
| Material | ASTM A36 / A572 Grade 50/65 Steel |
| Column Connection Method | High-Strength Bolted Splice Connections |
| Safety & Reliability | Compliance with ASCE 10-97 & IEC 60826 Standards |
| Wind Speed Capacity | Up to 180 km/h (Adjustable per site requirements) |
| Design Life | 50+ Years in Standard Conditions |
| Quality Certification | ISO 9001:2015 / CE / SGS Certified |
| Welding Standards | AWS D1.1 / GB/T 12467 |
| Included Hardware | Grade 8.8 Bolts, Nuts, Washers, and Grounding Kits |
| Application Range | 110kV – 750kV Overhead Transmission Systems |
